Product Specification

www.shuttle.com

Shuttle Computer Handels GmbH

Fritz-Strassmann-Str. 5

25337 Elmshorn | Germany

Tel. +49 (0) 4121-47 68 60

Fax +49 (0) 4121-47 69 00

[email protected]

e 1

ecember 2008

Maximum performance, packaged

with elegance

With its size of only 32.5 x 22 x 21 cm (DWH), this Mini-PC Barebone

in the H7-Design also accommodates the fastest Intel Core 2

processors with two or four cores. Up to 16 GB DDR2-800 memory

and three SATA2 hard disks can be installed. This XPC Barebone

SP45H7 uses the Intel P45 Express chipset and comes supplied with

Gigabit-LAN and many different connection options. Specific

options in the BIOS enable excellent opportunities to fine-tune the

clock cycle and voltage. The XPC Barebone SP45H7 will totally win

you over right down the line – whether as a workstation in a

professional environment or with large graphics cards as a

gaming cube.

Feature Highlight

H7 chassis

• Black aluminum chassis

• Drive bays: 1x 5.25“, 2x 3.5“

Chipset

• Intel P45 Express + ICH10

CPU

• Socket 775

• Supports Intel Core 2 Quad/Extreme/Duo,

Pentium Dual-Core, Celeron 4xx

• Supports 45 und 65nm CPUs

• Supports up to 1600MHz FSB

• Shuttle I.C.E. Heat-pipe cooling system

Slots

• 1x PCI-Express x16 (v2.0), 1x PCI

Supports dualslot graphics cards

Memory

• Supports 4x DDR2-667/800

• Up to 16 GBytes total size

Drive

connectors

• 3x SATA (internal)

• 3x External SATA (1x front, 2x rear)

• 1x IDE ATA 133, 1x floppy disk drive

Other

connectors

• 7.1-ch HD-audio, SPDIF output

• Firewire, GigaBit LAN

• USB 2.0 (2x front, 4x rear, 4x onboard)

Power supply

• 300 Watt mini power supply (80 PLUS)

Application

• Performance

Prduct ID: SP45H7

UPC (see bar code)

arebone

SP45H

Note: optical drive sold

separately. Images for

illustration purposes only.

1 2 3 4 5 6

Product Specification 1
